Specification

Model FD511G-X-F670
GPON/EPON Port Single mode single fiber
GPON : FSAN G.984.2 standard, Class B+
EPON : 1000BASE-PX20+ symmetric
Downstream/Upstream GPON : 2.488Gbps/1.244Gbps
EPON : 1.25Gbps
Wavelength Transmit : 1310nm
Receiver : 1490nm
Receiving sensitivity GPON : -28dBm
EPON : -27dBm
Saturated power GPON : -8dBm
EPON : -3dBm
Transmitting power GPON : 0.5 ~ 5dBm
EPON : 0 ~ 4dBm

User Port (LAN) 1*10/100/1000M Auto-negotiation RJ45 ports
Full/half duplex
RJ45, Auto-MDI/MDI-X
Transmission Distance 100 Meter
Power External 12V/0.5A DC power supply adapter
Power consumption <3W
Operating temperature 0 to 40ºC
Item Dimension 78 x 78 x 23.5 mm
Operating humidity 10% to 90%(Non-condensing)
